一种去雾算法

1. dev_update_off ()

2. dev_close_window ()

3. read_image (Image, 'tt (1)')

4. get_image_size (Image, Width, Height)

5. dev_open_window (0, 0, Width, Height, 'black', WindowHandle)

6. dev_display (Image)

7. disp_message (WindowHandle, '原图像', 'window', 12, 12, 'red', 'false')

8. *转换图像类型，用于后续运算

9. convert_image_type (Image, IxImage, 'real')

10. *求取暗通道图像

11. decompose3 (IxImage, R, G, B)

12. min_image (R, G, ImageMin)

13. min_image (ImageMin, B, ImageMin1)

14. gray_erosion_rect (ImageMin1, DarkChannelImage, 15, 15)

15. *计算全球大气光成分A的值

16. min_max_gray (DarkChannelImage, DarkChannelImage, 0.1, Min, Max, Range)

17. threshold (DarkChannelImage, Region, Max, 255)

18. min_max_gray (Region, IxImage, 0, Min1, A, Range1)

19. *计算透视率预估值tx

20. scale_image (IxImage, ImageScaled, 1/A, 0)

21. decompose3 (ImageScaled, R1, G1, B1)

22. min_image (R1, G1, ImageMin2)

23. min_image (ImageMin2, B1, ImageMin3)

24. gray_erosion_rect (ImageMin3, ImageMin4, 15, 15)

25. scale_image (ImageMin4, txImage, -0.95, 1)

26. *设定阈值T0，如果t<T0,则t=T0

27. T0:=0.1

28. threshold (txImage, Region1, 0, T0)

29. paint_region (Region1, txImage, txImage, T0, 'fill')

30. *求取去雾后的图像

31. scale_image (IxImage, ImageScaled1, 1, -A)

32. decompose3 (ImageScaled1, R2, G2, B2)

33. div_image (R2, txImage, ImageResultR, 1, A)

34. div_image (G2, txImage, ImageResultG, 1, A)

35. div_image (B2, txImage, ImageResultB, 1, A)

36. compose3 (ImageResultR, ImageResultG, ImageResultB, JxImage)

37. dev_open_window (0, 0+Width, Width, Height, 'black', WindowHandle1)

38. dev_display (JxImage)

39. disp_message (WindowHandle1, '去雾图', 'window', 12, 12, 'green', 'false')

复制代码

以下是雾图

你这又是网上copy的吧？有人已经发布过了
去雾算法的halcon代码实现
https://www.51halcon.com/forum.p ... =1472&fromuid=3
